Measuring Parameters:
Leads -12 Standard Leads
Mode of Operation – Auto / Manual
Long Lead Print – Yes
Test Performance – Auto mode: 3×4+IR, 3X4+3R, 6×2, 12, Manual mode: 3L, 6L, 12L
Display Lead – Yes
Display Type – 5″Color TFT
Display Resolution – 800 x 480 Pixels
Frequency Response – 0.05 to 150 Hz
Sweep Speed – 12.5/25mm/s
Sensitivity – 5/10/15/20mm/mV
CMRR – 105dB
Input Impedance – >10M Ohms
Patient Storage Data – 25 Patients
Printer Type – Thermal Printer
Paper Width – 210mm
Memory Stick Interface – Yes
Interpretation – Yes
Physical Characteristics:
Weight – 2.730Kg
Dimensions – 308(L)x240(B)x80(H)mm
Electrical:
Power Supply – 100-240VAC, 50-60Hz, 1.5A-0.8A
Power Consumption – 65 Watt
Filters – Digital AC/50Hz
Battery Rating – 11.1V, 4400mAh, Li-on Battery
Recharging Time – 4 Hours Max
Operating Time – >50ECG’s
Operating & Storage Condition:
Temperature – 5-55°C
Pressure – 50-160 Kpa
Humidity – Up to 90% Non-condensing
